Features Complies with RoHS directive AC input voltage range: 85-132/ 170-264VAC Selected by Switch Input frequency: 47-63Hz Inrush current: cold start, 20A/115V, 40A/230V Input leakage current: <0.7mA/230V Line regulation (Full Load): <± 0.5% Output voltage adj. range: ± 10% Output overload protection: 110-130% Constant Current, Auto Recovery Output over voltage protection: 115-150% Withstand voltage: I/P-O/P: 3.0KVAC/1min; I/P-F/G: 1.5KVAC/1min; O/P-F/G: 0.5KVAC/1min Rise time: 50ms@full load (typical) Hold up time: 20ms@full load (typical) Operating temp.& humidity: -10°C to 50°C (14°F – 122°F), 20%-93%RH (non-condensing) Storage temp.& humidity: -20°C to 85°C (-4°F – 185°F), 20%-93%RH (non-condensing) MTBF: 100,000 hours
